MKD071B-061-KG0-KN
MKD071B-061-KG0-KN
Manufactured By BOSCH INDRAMAT
Description
- MKD071B061KG0KN
- SYNCHRONOUS SERVO MOTOR
- MKD SERIES
- 1.7-7.7 AMP
- 283-380 V
- 267-333 HZ
- 6000 R/MIN MAX
- 071 MOTOR SIZE
- MOTOR LENGTH B
- 061 WINDING CODE
- MULITURN ENCODER
- RESOLVER FEEDBACK
- PLAIN SHAFT
- WITH SEALING RING
- PERMANENT MAGNET
- 0 TO 40 DEGREE C
- IP65
- FOR REPAIR OR BUYING NEW, PLEASE CONTACT US AT (888) 932-9183 OR (905) 829-2505
Specifications
| Part # | MKD071B-061-KG0-KN |
|---|---|
| Category | Servo Products |
| Subcategory | Servo Motor |
| Motor Size | 071 Motor Size |
| Motor Length | Motor Length B |
| Windings Code | 061 Winding code |
| Motor Encoder | Resolver Feedback with Integrated Multiturn Absolute Encoder |
| Driven Shaft | Plain Shaft (With Shaft Seal Ring) |
| Holding Brake | Without Holding Brake |
| Output Direction Power Connection | Terminal Box |
| Housing Design | Standard Housing |
If you need a specific firmware or series relating to MKD071B-061-KP1-KN, we probably have it. Please call or email us with your request.
MKD071B-061-KG0-KN- Repaired and Tested
New Product with Accu’s 1-year warranty
Call (905) 829-2505 for lead time
Note: Price is Canadian Dollars
LIMITED STOCK
Order Now!
Out of stock
Choosing to REPAIR your product can save you money and help reduce waste. Our expert technicians will ensure your product works like new!
Buy Now or Request Repair via below form or Call us @ 1-888-932-9183
Procedure for sending in a Repair
- As we receive your shipment, we assign an RMA tracking number
- After doing a thorough inspection we give the estimate on cause of failure, what’s required to get it back up and running, and quote you the repair
- After repair and reassembly the lead technician will adjust the alignment angle and run-test the motor on the original OEM drive, not a standalone universal drive as our competitors. This ensures the motor works exactly how it would in your system. Our vast investment in harnesses and drives makes this process quick, safe, and cost-effective for you to get your machine back online fast.
- Once completed the motor is packed, with foam in a secured box for shipping, and customer is sent the tracking number.
